因配置不同價格也有所差異 以上配置和價格僅供參考詳細請電話咨詢銷售經理
整機基本參數Basic parameters of the whole machine 整機重量Total weight 7100KG
運輸時總長shipping length 6346(mm)
運輸時總高
Total height during transportation 2800(mm)
運輸寬度
Transport width 2200(mm)
輪胎中心距離Tire center distance 2400(mm)
配重離地間隙
Counterweight ground clearance 1035(mm)
輪胎數量umber of tires 8-825
動臂長度Boom length 3800(mm)
斗桿長度Stick length 2000(mm)
工作范圍
Working Range 大挖掘高度Max.Digging Height 6550(mm)
大卸載高度Max.Dumping Height 5100(mm)
大挖掘深度Max.Digging Depth 3380(mm)
大挖掘范圍Max.Digging radius 6590(mm)
推土鏟大提升高度
Maximum lifting height of earth shovel 300(mm)
推土鏟大掘地深度
The maximum digging depth of dozer 100(mm)
動力系統Dynamical system 發動機型號Model 揚動
額定功率power 55KW
冷卻方式Cooling method 水冷渦輪增壓
Water cooled turbocharging
液壓系統Hydraulic System 額定工作壓力Operating Pressure 22mpa
液壓泵Main pump 變量柱塞Variable plunger
液壓閥 韓國進口Korea
形式Shape 負載敏感系統
Load Sensing System
性能參數performance parameter 鏟斗容量（SAE）Bucket Capacity 0.36m3
爬坡能力Climbing ability 30°
大挖掘力Maximum digging force 8200N
行走速度Travel speed 35KM/h
回轉速度Unit swing speed 9-11r/min
液壓油容量Hydraulic oil capacity 90L
燃油箱容量Hydraulic tank capacity 120L
駐車制動Parking brake 斷氣剎Air break
行車制動service brake 氣剎Kill
穩定裝置Stabilizers 支腿/選裝Legs / optional

查看全部介紹
